Blown head gasket? We diagnose first, then repair it properly

A head gasket does not simply wear out. It fails because something let the engine overheat, or because combustion pressure found a weak point in the seal, and the same symptoms can be caused by faults that have nothing to do with the gasket. A weeping radiator, a tired water pump, a stuck thermostat or a cracked coolant hose can all lose coolant and run an engine hot. Condemning the head gasket without confirming it means stripping an engine you did not need to touch.

That is why every head gasket job here starts with testing, not spanners. A cooling system pressure test shows where coolant is going, and a combustion leak test shows whether exhaust gases are getting into the coolant, the tell-tale sign of a breached gasket. We look most often at:

• Overheating with no visible external leak
• White exhaust smoke and a sweet coolant smell
• Milky oil, or coolant that keeps needing topping up

Only once the test results point clearly at the gasket do we quote the strip-down.

Getting this right at the front end saves you the most money. A cooling fault caught early might be a thermostat and a coolant flush. The same fault ignored for a week of hot running warps the head, cracks it, or scores the block, and turns an afternoon repair into a multi-day rebuild with machine-shop time on top. The single most useful thing you can do is stop driving an engine the moment it overheats and let us test it cold.

Diagnosis: the job begins with a full set of tests so we are certain of the fault before any labour is spent pulling the engine apart.

• Cooling system pressure test to trace coolant loss
• Combustion leak test for exhaust gases in the coolant
• Compression and cylinder leak-down testing across all cylinders
• Oil and coolant checked for cross-contamination
• Fault-code scan with manufacturer-level scan tools for misfires and overheating codes

We also check the radiator, water pump, thermostat and cooling fans at this stage. A head gasket is almost always the second failure, the overheating that caused it is the first, and both have to be fixed together.

The repair: once the gasket is confirmed, the cylinder head is removed and inspected.

• Head, block face and old gasket inspected for warping, cracking and erosion
• Head flatness measured with a straight edge and feeler gauges against manufacturer tolerance
• Genuine or OEM-spec head gasket, head bolts and seals fitted to specification
• Head bolts torqued in the correct sequence and angle, replaced where they are torque-to-yield
• Cooling system refilled, bled and pressure rechecked

If the head is warped or cracked, it needs machining, and that is specialist engineering work. We are straight with you about this: the head goes to a trusted machine shop for skimming, crack-testing and pressure-testing, then comes back to us to go on the engine. We do not claim to do that machining in-house, and we build the machine-shop time into the quote so there are no surprises.

Petrol versus diesel: the principle is the same across both, but the detail differs. Diesels run far higher compression, so they usually use multi-layer steel gaskets and stretch-style head bolts, and their heads warp more readily when they have been run hot. Petrol engines more often let go after a cooling-system failure. We match the parts, the torque procedure and the checks to your specific engine, whether it is a Corolla, a Ranger, a Hilux or a fleet van.

Rebuild, not just reassembly: while the head is off is the sensible time to deal with anything else the strip-down exposes. Timing belts and tensioners, water pumps, thermostats and hoses are often already out of the way or due, and replacing them now costs far less in labour than going back in later. We flag these as we find them, with the cost of each so you can decide, rather than quietly adding parts to the bill.

Phone (07) 847 3339 with the symptoms: overheating, white smoke, coolant vanishing, milky oil, or an engine that has already run hot. We book the vehicle in for a diagnostic slot and, importantly, ask you not to keep driving it, because every extra hot kilometre risks warping the head and turning a gasket job into a much bigger one.

On the day, the testing comes first. We pressure test the cooling system, run the combustion leak test, check compression and leak-down, and scan for codes. If the tests confirm the gasket, we work out what let the engine overheat in the first place and quote the full job, the gasket, the parts, any machine-shop time, and the underlying cooling fault, before we start. Nothing gets stripped without your sign-off.

Once approved, the head comes off, goes away for machining if it needs it, and is rebuilt with genuine or OEM-spec parts torqued to manufacturer specification. We refill and bleed the cooling system, bring the engine up to temperature, and road test it. You collect with a written report covering what was found, what was replaced and what we recommend watching.

Head gasket repairs have a wider price range than almost any other job, because the labour to reach the head and the state of the engine after overheating both vary enormously. We quote each one specifically once the vehicle has been tested:

• Engine type - a small petrol four is far quicker to reach and rebuild than a diesel or a large multi-cylinder engine
• Access - some engines need the intake, exhaust, cambelt or timing chain removed to get the head off, which adds hours
• Machining - a head that is flat and sound goes straight back on; one that is warped or cracked needs specialist machine-shop skimming, crack-testing or pressure-testing
• Collateral damage - an engine driven badly overheated may need more than the gasket, and we will show you exactly what and why
• Parts grade - genuine versus quality OEM-spec gasket sets and bolts, matched to your engine

Across New Zealand, a cylinder head gasket repair typically costs between $1,500 and $4,500, though the exact price depends on your vehicle and the extent of the work, particularly whether the head needs machining. For an accurate quote for your vehicle, call (07) 847 3339 or use the contact form.

Our workshop is on Kahikatea Drive in Frankton, three minutes from the Hamilton ring road. Engine repair work comes to us from right across the wider Waikato: daily-driver utes and cars from Hillcrest, Rototuna, Te Rapa and Chartwell, and from Cambridge, Te Awamutu, Morrinsville, Huntly, Ngaruawahia and out toward Raglan, plus fleet vans and light commercials whose owners cannot afford a guessed repair.

A head gasket is a multi-day job, more so when machining is involved, and we confirm the likely timing at the diagnostic stage so you can plan around being without the vehicle. The workshop is open Monday to Friday, 7:30 AM to 4:30 PM. If you have an overheating engine, the best thing you can do is stop driving it and call us before the damage spreads.
